You can activate the Auto start option –> Checkbox Auto. Use the slider to navigate through the audio file during playback.įor performance reasons, the audio level indicators are active only when the window is in focus. When you press Delete, the file will be moved to the trash without a further warning. You can rename or delete the file using the provided controls. The option is labled Overwrite existing file. This can save you some time by not having to delete, rename, and reassigning the file.
When you make a recording for the voice keyer you may want to overwrite an existing file. The file is named: YYYY-MM-DD_HH-MM-SS.m4a and will be saved to the user’s Library directory at: ˜/Library/Containers/de.dl2rum.RUMlogNG/Data/
Only those files that have been saved to the Voicekeyer_Recordings folder are accessible for the voice keyer.
The wires to these connectors come pre-stripped and tinned for quick and painless final assembly to match the pin out requirements for your particular equipment. The VKC-4/8 cables provide the connection between the VK-64 and your rig and microphones. Rear Panel Connectors & Controls Power: Center positive Transmitter and Microphone Audio: DB9 Computer: DB25 CW Paddle: 1/8" Stereo Phono CW Out: RCA Phono Audio Level Adjust: Trim pot adjust
#Flexradio voice keyer rumlogng software
Power: 12V DC, 500 ma Audio Messages:4 messages, 15 seconds each CW Output keying: Solid state, for positive keyed rigs only Software compatibility: N1MM Logger, CT, NA, TR-LOG The VK-64-DX comes without a power supply for stations that use a different power connectors or otherwise want to supply their own 12VDC.
#Flexradio voice keyer rumlogng manual
Adding computer control only needs a standard 25 pin shielded computer cable between theĬables are not included, but can be easily made according to directions in the manual orĪ 12V wall transformer with US standard 2 prong plug is included with the VK-64. Transmitter, even when the VK64 is powered off.ĬW set up is as simple as plugging your paddle into the VK-64. Microphone audio and PTT signals pass through the VK-64 and connect directly to the Plug the microphone into the VK-64's microphone input cable. Installing the VK-64 is easy! Unplug the microphone and plug the VK-64's transmitter audio/PTT cable
The VK-64 is compatible with the major contest logging programs, including N1MM Logger, NA, WriteLog, TRLog, CT and LogEQF. The delay time can be adjustedįrom approximately 1/2 to 12 seconds with a front panel control. Message 1 for both CW and voice modes can be set up for auto repeat. Logging programs support sending CW through the printer port.Ĭomputer keying works in parallel with the internal CW keyer. The VK-64 also includes a built in LPT CW interface. A front panel knob adjusts speed from 8-45 WPM. The CW portion is an iambic memory keyer with four programable messages, each one capable of storing over 300 Morse characters. Messages are stored in non-volatile memory, remaining stored until recorded over with a new message. Press the stop button when you are finished. Press the record button followed by a message number button and start talking. The voice keyer section has four 15 second messages.
#Flexradio voice keyer rumlogng Pc
You can operate the VK64 manually with the front panel controls or under program control through your PC or laptop's printer port. The VK-64 is a voice keyer and CW memory keyer in the same package! This is a legacy product and is no longer available. Unified Microsystems: W9XT VK-64 Combo Voice Keyer/CW Memory Keyer and more for ham radio operators!
